Type : 2 channel active DI
Width : 215 mm(8.465inch )
Height : 50 mm(1.969inch )
Depth : 125 mm(4.921inch )
Weight : 1 kg(2.205lb )
Rack Units : 1/2 rack unit
Removing the two molded sides and attaching two units, with the supplied brackets, you can mount two by two DI boxes into a standard 19? rack.
Power Supply : Phantom Power: +24 volts DC to +48 volts DC
External AC/DC adaptor: +9 volts DC with link
Standalone/Standby: 9 volt PP3 type battery.
Current drain : < 8 mA
Inputs : Two Parallel 1/4" jack connectors and one parallel RCA connector (unbalanced).
Input Impedance : 200 kOhm (pad at 0 dB)
47 kOhm (pad at -20 dB)
44 kOhm (pad at -40 dB)
Input Levels : +5 dBu (pad at 0 dB)
+25 dBu (pad at -20 dB)
+35 dBu (pad at -30 dB)
Outputs : XLR male: Pin 2 Hot / Pin 3 Cold / Pin1 Ground
Output Impedance : 50 ohm
Output Levels : into 600 Ohms or greater
+5 dBu (for 0.1% THD at 50 Hz)
+5 dBu (for 0.1% THD at 1k Hz)
Band width : from 10 Hz to 70 kHz, +0dB/-1 dB
Channels : 2 nr.
Distortion (THD) : < 0.007 %
S/N Ratio : < -105 dBu unweighted
Controls : On/off, Pad -20, Pad -30, Gnd Lift.
Notes : Phase distortion +4° at 20 Hz, -13° at 20k Hz
