Neck

Fingerboard MaterialCaramelized Maple
Fingerboard Radius12"-16" Compound Radius (304.8 mm to 406.4 mm)
HeadstockReverse Licensed Fender® Telecaster®
Neck ConstructionBolt-On with Graphite Reinforcement
Neck FinishHand-Rubbed Satin Urethane
Neck MaterialCaramelized Maple
Neck ShapeSpeed Neck with Rolled Fingerboard Edges
Number of Frets24
Nut MaterialGraph Tech® TUSQ® XL
Nut Width1.6875" (42.86 mm)
Position Inlays4mm Pearloid Dot
String NutGraph Tech® TUSQ® XL
Truss RodDual-Action with Wheel
Truss Rod NutHeel-Mount Truss Rod Adjustment Wheel

Hardware

BridgeGotoh® Custom 510 Tremolo
Control KnobsDome-Style
Hardware FinishBlack
Neck PlateNone - 4-Bolt Sculpted Heel
Pickguard1-Ply Black
Pickup CoversBlack
Strap ButtonsStandard
String TreesFender® Standard String Guide
StringsNickel Plated Steel (.009-.042 Gauges)
Switch TipBlack
Tremolo ArmGotoh®
Tuning MachinesCharvel®-Branded Die-Cast Locking

Body

BodyAsh
Body FinishSatin
Body MaterialAsh
Body ShapeSo-Cal Style 2
Body StyleSolid Body

Electronics

Auxiliary Switching2-Way Mini Toggle (Switches Between Voice 1 and Voice 2)
Bridge PickupFishman® Fluence® Open Core PRF-COC
ControlsVolume, Tone (with Push/Pull Activation for Voice 3)
Neck PickupFishman® Fluence® Open Core PRF-COC
Pickup ConfigurationHH
Switching3-Position Blade: Position 1. Bridge Pickup, Position 2. Both Humbuckers, Position 3. Neck Pickup - (Push/Pull Tone Knob) - Position 1. Bridge Single Coil, Position 2. Both Bridge and Neck Single Coils, Position 3. Neck Single Coil
