Acoustical Specifications

Frequency Response -3 dB: 50 Hz ÷ 20 kHz
Max SPL: 127 dB
Horizontal coverage angle: 90°
Vertical coverage angle: 70°
Compression Driver: 1" neo, 1.5" v.c.
Woofer: 10" neo, 2.5" v.c

Input/Output Section

Input signal: bil/sbil
Input connectors: xlr
Output connectors: xlr
Input sensitivity: 0 dBu
Mic. Input Sensitivity: -40

Processor Section

Crossover frequencies: 1800 Hz
Protections: DC / corto cir
Limiter: Fast limiter
Controls: Volume

Amplifier Specifications

Total power: 350 W
High frequencies: 50 W
Low frequencies: 300 W
Cooling: Convenzione
Connections: VDE connector in

Cabinet

Cabinet Material: PP composito
Hardware: 2xM10 flying p.
Handles: 1 sopra
Pole Mount/Cap: Si
Colour: Nero

Physical Specifications

Height: 537 / 21.14 mm/inch
Width: 337 / 13.26 mm/inch
Depth: 315 / 12.40 mm/inch
Net Weight: 12.4 / 27.33 kg/lbs
